Air Shower Chamber is a buffer device between the clean area and the non-clean area. It's function is to sweep the dust particles attached to the surface of people or objects entering the clean room through high-speed clean airflow, effectively intercept 99.99% of particles ≥0.3 μm, prevent external pollution sources from entering the clean area, ensure the stability of the indoor environment, and extend the service life of the HEPA filter.
The role of Air Shower Chamber
In places such as pharmaceuticals, medical devices, food, and biological laboratories, dust particles in the air will affect product safety and production yield. The configuration of an intelligent Air Shower Room can effectively reduce the number of particles entering the clean environment, thereby ensuring that the process environment meets the standards, avoiding product contamination, and improving production safety and product yield.
Air Shower Room with double blow supports two-way blowing. No matter which direction the personnel enter and exit, the equipment can automatically detect and start high-intensity clean airflow, and blow away dust particles attached to the surface of the human body, work clothes or goods from multiple nozzles at the same time.
18 Nozzles, Stainless Steel Air Shower nozzles with adjustable angles, are reasonably distributed to ensure that the airflow covers all parts of the body and avoid cleaning dead corners.
Intelligent Air Shower product core features
- H13 double filtration system
- Wind speed ≥25m/s, two-way shower, 360° shower without dead angles
- PLC intelligent program control system
- Corrosion-resistant 304 stainless steel structure
Air Shower Room Price Influencing Factors
- Size customization: Single/Double/Cargo showers have different sizes, and the prices vary.
- Number of nozzles and wind speed configuration: The more nozzles, the higher the wind speed, and the higher the cost.
- Filter level: H13, H14 different configurations, different prices.
- Intelligent control system function: Intelligent air shower rooms with automatic detection, remote monitoring, and alarm devices are slightly more expensive, but the user experience and safety are better.
Specifications
| Model |
FLS-1300-2 |
| Size mm (W*D*H) |
1300*1500*2050 |
| Inner size mm (W*D*H) |
800*1420*1920 |
|
Applicable no. of persons
|
2-4 people |
| Filter size mm |
610*610*100*2 |
|
Filter efficiency
|
99.99% @0.3 μm |
| Moto Power |
1.1KW*2 |
| No. fo Nozzle |
18 |
| Air speed |
18-22m/s |
|
Showing time
|
10-99s adjustable, set 15s |
| Noise |
＜65dB |
| Voltage |
AC 220v/380V/50HZ |
FAQ
Q1: How does the air shower room ensure the cleanliness?
A: The air shower room uses a built-in high-efficiency filter (H13 grade) and multi-nozzle high-speed airflow (≥25m/s) to blow away dust, bacteria and other particles attached to the surface before people or objects enter the clean area. With a double filtration system, it ensures that the air cleanliness entering the clean room meets ISO 5-8 standards to avoid pollution sources.
Q2: What places are this intelligent air shower room suitable for?
A: Double Blow 18 Nozzles Intelligent Air Shower is widely used in pharmaceutical workshops, hospital operating rooms, food processing plants, electronic semiconductor clean rooms, biological laboratories and other environments with high cleanliness requirements.
